Product Overview
General Information
Name : 8port Managed Midspan POE 220v , Altronix
Category : PoE Injectors
UPC Code :
Country of Origin : United States. Country of origin is subject to change.
Specifications
General Information
ADI Part Number : AX-NET8MV
Manufacturer Part Number : NETWAY8MV
Maximum Transfer Distance : 1968.5'
Product Line : NetWay
Product Model : NETWAY8MV
Product Name : Midspan Injector, 16 Port, 10/100, PoE/PoE+, 150W, 220VAC, Shutdown Trigger, Web Browser
Product Series : NetWay
Product Type : PoE Injector
Technical Information
Output Voltage : 48-57V
Wireless LAN Standard : IEEE 802.3af, IEEE 802.3at
Certifications
NDAA Compliant : Yes
Environmental Conditions
Operating Relative Humidity (H-H) : 0.85
Operating Temperature (T-T) : -4-104°F
Storage Temperature (T-T) : -4-158°F
Interfaces/Ports
Input Ports : 1 x 10/100 BaseT
Physical Characteristics
Depth : 8.5"
Height : 1.63"
Rack Height : 1U
Rack Width : 19"
Weight : 8.1lb
Width : 19.13"
Power Description
Frequency : 60 Hz
Input Voltage : 220V AC
Maximum Frequency : 60 Hz
Maximum Input Current : 1.5A
Maximum Output Power : 150W
Power over Ethernet (PoE) : Yes
Product Information
Mount Type : Rack Mount
Protection Type : Short Circuit Protection
Warranty
Limited Warranty : Lifetime
Miscellaneous
Additional Information : Port Status LEDs
Certifications : UL 294
Certifications & Standards : CE, IEEE 802.3af, IEEE 802.3at
Country of Origin : US
Environmental Certification : CE
